QJM Hydraulic Motor in Mumbai Maharashtra India
QJM Hydraulic Motor it is Spherical Piston ( Ball Piston ) type Hydraulic Motor that can be used to establish a Hydraulic Actuator with various oil flow, valves and hydraulic parts can adapt itself to all kinds of mechanical conditions by reason of some contacts taken to its project.
We have various models and sizes in QJM series Motors from 83 C.C to 10150 C.C, with Single, dual and triple speed and with or without brake and with special mounting.
FIXED DISPLACEMENT
1QJM001, 1QJM002, 1QJM01, 1QJM02, 1QJM11, 1QJM21, 1QJM32, 1QJM42, 1QJM52, 1QJM62
VARIABLE SPEED DUAL DISPLACEMENT
2QJM001, 2QJM002, 2QJM01, 2QJM02, 2QJM11, 2QJM21, 2QJM32, 2QJM42, 2QJM52, 2QJM62
VARIABLE SPEED TRINAL DISPLACEMENT
3QJM32
- Because the rolling body of this motor is replaced by a steel ball rather than two or more rollers and beams commonly used in inner curve hydraulic motors, it is simple in structure, reliable in performance and greatly reduced in volume or weight.
- A small kinematics' pair inertia and a hard steel ball make this motor continuously work during the rotation at higher speed and under stronger impact load.
- It has higher mechanical and volumetric efficiency for its small friction pair, oil feed shaft balanced with roller, piston pair capable of static pressure balance & good lubrication and coated high pressure sealing oil on soft plastic mat.
- As the oil feed shaft and stator are in rigid connection, the oil pipeline of this model can be connected with steel pipe.
- As this model has variable displacements dual and trinal speeds, it is wider in speed regulating range.
- Simple structure and easy maintenance.
- That one of Z series hydraulic motor can endure outside radial and axial forces. As T series hydraulic motor has a central through hole, the rotating shaft can pass through the motor.
| Series | QJM001 | QJM01 | QJM11 | QJM12 | QJM21 | QJM32 | QJM42 | QJM52 | QJM62 | |
| Flow rate L/min | 50 | 63 | 80 | 80 | 100 | 160 | 250 | 320 | 400 | |
| Outer diameter(mm) | Ø140 | Ø180 | Ø240 | Ø240 | Ø300 | Ø320 | Ø350 | Ø420 | Ø485 | |
| · Plastics Processing Machinery | · Geological Prospecting |
| · Pedrail walking | · Driving Railway wheels |
| · Different slewing gears | · Drilling |
| · Winch hoisting | · Belt transmission |
| · Material agitation | · Cutting road surfaces |
| · Ship propulsion | · Plastic injection |
| · Mine engineering | · Hoisting transport |
| · Metallurgy | · Ships / Marine Equipment |
| · Machine tools | · Heavy Machinery |
| Light Weight | Compact Size |
| Wide range of speed control | Consistency in performance |
| Long lift | High Torque Output |
| High Efficiency | Smooth Operation |
| Low Noise Level | Break Option Available |
