QJM Sphere Piston Hydraulic Motor
QJM hydraulic motor that can constitute a hydraulic actuator with different oil pumps, valves and hydraulic parts is able to adapt itself to all kinds of mechanical conditions by reason of some measures taken to its design.
JM hydraulic motor it is sphere type motor that can be used to constitute a hydraulic actuator with various oil flow, valves and hydraulic parts can adapt itself to all kinds of mechanical conditions by reason of some measures taken to its design.
This motor offers many benefits as follows…
1. Light Weight2. Compact Size3. Wide range of speed control4. Consistency in perfomance5. Long lift
QJM – Sphere type hydraulic Motor Can be used in following industries…
1. Mining Engineering2. Metallurgy3. Ships4. Plastic Processing Machines5. Hoisting Transport
The main use of QJM – Sphere type motor is to walk pedrail, to drive railway wheels, to hoist winch, to transmit belt, to cut road surface…
QJM With External Shaft Version Motor
QJM With Hollow Shaft Version Motor
Key Features:
High Torque: They can generate substantial torque, especially at low speeds.
High Pressure Capability: They are designed to operate under high hydraulic pressures.
Precise Control: They offer accurate speed and torque control.
Efficiency: They can achieve high volumetric and mechanical efficiency
| Technical Data for QJM Series Hydraulic Piston Motor with outside control brake | |||||||
| Type | ml/rev) Displacement |
(MPa)Pressure | (r/min) Speed Range |
(N.m) Output torque |
(MPa) Brake start pressure |
Brake Torque | |
| Rated | peak | ||||||
| 1QJM12-0.8Se,Sez | 0.808 | 10 | 16 | 4-250 | 1076 | 1.3≤P≤6.3 | ≥1800 |
| 1QJM12-1.0Se,Sez | 0.993 | 10 | 16 | 4-200 | 1332 | ||
| 1QJM12-1.25Se,Sez | 1.328 | 10 | 16 | 4-160 | 1771 | ||
| 1/2QJM21-0.32Se,Sez | 0.317 | 16 | 25 | 2-500 | 751,376 | 2.5≤P≤6.3 | ≥2500 |
| 1/2QJM21-0.40Se,Sez | 0.404 0.202 | 16 | 25 | 2-400 | 957,479 | ||
| 1/2QJM21-0.50Se,Sez | 0.496 0.248 | 16 | 25 | 2-320 | 1175,588 | ||
| 1/2QJM21-0.63Se,Sez | 0.664 0.332 | 16 | 25 | 2-250 | 1572,786 | ||
| 1/2QJM21-0.80Se,Sez | 0.808 0.404 | 16 | 25 | 23-200 | 1913,957 | ||
| 1/2QJM21-1.0Se,Sez | 1.01 0.505 | 10 | 16 | 2-160 | 1495,748 | ||
| 1/2QJM21-1.25Se,Sez | 1.354 0.677 | 10 | 16 | 2-125 | 2004,1002 | ||
| 1/2QJM21-1.6Se,Sez | 1.65 0.825 | 10 | 16 | 2-100 | 2442,1221 | ||
| 1/2QJM32-0.63Se,Sez | 0.635 0.318 | 20 | 31.5 | 3-300 | 1880,940 | ≥6000 | |
| 1/2QJM32-0.8Se,Sez | 0.808 0.404 | 20 | 31.5 | 3-250 | 2368,1184 | ||
| 1/2QJM32-1.0Se,Sez | 0.993 0.497 | 20 | 31.5 | 2-250 | 3138,1569 | ||
| 1/2QJM32-1.25Se,Sez | 1.328 0.664 | 20 | 31.5 | 2-200 | 3833,1942 | ||
| 1/2QJM32-1.6Se,Sez | 1.616 0.808 | 20 | 31.5 | 2-200 | 4881,2441 | ||
| 1/2QJM32-2.0Se,Sez | 2.03 1.355 | 16 | 25 | 2-200 | 4807,2404 | ||
| 1/2QJM32-2.5Se,Sez | 2.71 1.055 | 10 | 16 | 1-160 | 4011,2006 | ||
| 1/2QJM32-3.2Se,Sez | 3.3 1.65 | 10 | 16 | 1-125 | 4884,2442 | ||
| 1/2QJM32-4.0Se,Sez | 4.0 2.0 | 10 | 16 | 1-100 | 5920,2960 | ||
| 1/2QJM42-2.0Se,Sez | 2.11 1.055 | 20 | 31.5 | 1-250 | 6246,3123 | 2.1≤9≤6.3 | ≥9000 |
| 1/2QJM42-2.5Se,Sez | 2.56 1.28 | 20 | 31.5 | 1-250 | 7578,3789 | ||
| 1/2QJM42-3.2Se,Sez | 3.3 1.65 | 10 | 16 | 1-200 | 4884,2442 | ||
| 1/2QJM42-4.0Se,Sez | 4.0 2.0 | 10 | 16 | 1-160 | 5920,2960 | ||
| 1/2QJM42-4.5Se,Sez | 4.56.28 | 10 | 16 | 1-125 | 6808,3404 | ||
| 1/2QJM52-2.5Se,Sez | 2.67 1.355 | 20 | 31.5 | 1-200 | 7903,3952 | 2.2≤P≤6.3 | ≥10000 |
| 1/2QJM52-3.2Se,Sez | 3.24 1.62 | 20 | 31.5 | 1-200 | 9590,4795 | ||
| 1/2QJM52-4.0Se,Sez | 4.0 2.0 | 16 | 25 | 1-200 | 9472,4736 | ||
| 1/2QJM52-5.0Se,Sez | 5.23 2.615 | 10 | 16 | 1-160 | 7740,3870 | ||
| 1/2QJM52-6.3Se,Sez | 6.36 3.18 | 10 | 16 | 1-125 | 9413,4707 | ||
